1610- Large laser engraving & cutting machine

LASER TABLE

Large size of laser sheet frame makes F1610 more easily be refitted into a ultimate series machine for bulk production.

INDUSTRIAL ELITE
Due to a large working area of 1600*1000mm, it benefits you to load a whole material sheet just in one time. The 1100mm/s work speed, and the powerful, stable CO2 laser source make this system reach a massive bulk production in a high rates.
LASER ENGRAVER AND CUTTER
AVast variety of materials, like, acrylic, wood, rubber, paper card, plastic, glass, can be handled in a professional way. The F1610 industrial laser Cutter has necessaries accessories such like a collection drawer, a removable honeycom table or knife table, which makes it as a engraver sometimes. Due to Laser Size of its metal sheet frame, it can adpot even 180w laser tube to achieve a high bulk production.
PERSIONALIZATION DESIGN TO AVOID FAULTS
Circuit breaker reset function can solve the emergency situation, F1610 will always keep memory of cutting progress under any situation. Don’t be nervous to stop machine at any time or at any case. Red-dot device can easily solve the focus issue and start-point issue, you shall never miss the right point to start your cut job.

Download the brochure Download Gravotech Overview

Technical Specifications

Integrated air compressor to keep the lens clean and ensure high-quality engraving results.
Protect the focal lens by pushing the fumes towards the exhaust area and reduce flaming when cutting.
This also increases the life span of lenses and creates safer working conditions for the user.

Red Dot: Auxiliary red dot helps find out focus easily.

Embedded board allows modifying the job and fine-tune the settings.

Dedicated software

Point and shoot: Easy positioning and job set-up.
Print and cut: precisely cut printed products, without the need for additional materials.
Multi-technology software, allowing to centralize designs settings, experience, and knowledge into a single work environment.

General

Source laser
CO2
Available power version
130W - 150W - 180W

Engraving Capacity

Working area max (l x w)
1600 x 1000 mm (63.1 x 39.4 in)
Available lens (in)
20mm
Max object height
145 mm (5.7 in)

	F1610
Dimensions (L x W x H)	2230 mm x 1530 mm x 1200 mm (87.8 in x 60.3 in x 47.3 in)
Cutting Area	1600mm*1000mm (23.6 in x 15.7 in)
Machine weight	550 kg (330.7 lb)
Laser Tybe	Sealed CO2 Galss tube 100w/150w/180w
Laser safety classification	CDRH: Class 2
Engraving Speed:	1-60000mm/min
Resetting Positioning Accu	±0.01mm
Automatic Z axis	145 mm (5.7 in)
Beam diameter	0.1 mm to 0.4mm (0,004 in to 0,016 in)
Compatible Software:	CorelDraws, Autocad, Photoshop
Supported File:	PLT, AI, DXF, DST, BMP, JPGE
Software	RD, TROCEN
Cooling Mode:	Water Cooling
Noise level	≤ 70 dB
Connection to computer	USB, Ethernet
Power	AC220±10%/ AC110±10%, 50/60HZ
Working Environment:	Temperature:0-30℃; Humidity:30-80%
